After the Betaflight firmware, configurator, and Blackbox Explorer posts, dRehmFlight VTOL is a useful change of angle.

Betaflight is the polished FPV firmware ecosystem.

dRehmFlight is closer to a teaching bench.

It is an Arduino/Teensy flight-controller codebase for people who want to understand, modify, and prototype stabilization logic for unusual VTOL aircraft.

That makes it interesting for the same reason the ExpressLRS recovery story was interesting: when hardware is involved, source code is not abstract.

It touches pins, sensors, timing, radio input, arming logic, ESC output, and safety assumptions.

dRehmFlight VTOL is an open-source Arduino-compatible flight-controller project built around Teensy, an IMU, receiver input, attitude estimation, PID control, and custom motor/servo mixing for experimental VTOL aircraft.

dRehmFlight GitHub Source Code dRehmFlight VTOL Project Page RC Groups Support Thread License: GPL-3.0

What is dRehmFlight?

dRehmFlight is flight-controller firmware for custom radio-control aircraft.

The important part is not that it can stabilize a normal quad.

The important part is that the code is intentionally readable and concentrated enough that you can follow the full path:

receiver input
  -> desired roll, pitch, yaw, throttle
  -> IMU data
  -> attitude estimate
  -> PID controller
  -> custom motor and servo mixer
  -> ESC and servo output

That is the workflow hidden inside every serious flight controller.

dRehmFlight exposes it in a way that is friendly to Arduino users.

The upstream project is clear about its purpose: it is for hobbyists, hackers, non-coders, teaching, rapid prototyping, and unusual VTOL experiments. It is not presented as a commercial or performance replacement for mature flight-controller packages.

That honesty is good.

It sets the right expectation before anyone tries to put code on aircraft hardware.

Why It Matters

Most drone firmware discussions quickly become tool discussions:

  • which target to flash
  • which configurator tab to open
  • which preset to apply
  • which UART should carry CRSF
  • which blackbox trace proves the tune is good

Those are practical questions.

But they can hide the actual control loop.

dRehmFlight is useful because it lets you inspect the control loop directly.

In the latest Beta 1.3 sketch I inspected, the main loop is legible:

armedStatus()
getIMUdata()
Madgwick(...)
getDesState()
controlANGLE()
controlMixer()
scaleCommands()
throttleCut()
commandMotors()
getCommands()
failSafe()
loopRate(2000)

That is a compact way to learn what flight-controller firmware is doing before you get lost in a larger embedded codebase.

Repository Snapshot

I cloned and inspected:

repo: https://github.com/nickrehm/dRehmFlight
HEAD: 0df49c5d
describe: 0df49c5
license: GPL-3.0
latest sketch inspected: Versions/dRehmFlight_Teensy_BETA_1.3

Recent repository activity in this checkout was mostly README maintenance plus a fix for an asin NaN possibility when pitch is 90 degrees.

The project layout is simple:

Path What It Contains
README.md project overview, hardware, software, tutorial links, flight examples
dRehmFlight VTOL Documentation.pdf long-form setup and concept documentation
Versions/dRehmFlight_Teensy_BETA_1.3/ latest Arduino/Teensy sketch inspected
dRehmFlight_Teensy_BETA_1.3.ino main flight-controller sketch
radioComm.ino receiver input setup and radio channel handling
src/MPU6050, src/MPU9250 bundled IMU support code
src/SBUS, src/DSMRX, src/TFMPlus bundled receiver/sensor support libraries

This is not a Docker project.

It is not a browser PWA.

It is embedded Arduino-style firmware for a physical flight controller.

Hardware and Software

The default build is centered on:

  • Teensy 4.0
  • Teensy 4.1 compatibility with the same pin mappings
  • GY-521 MPU6050 6-axis IMU over I2C
  • optional MPU9250 over SPI
  • Arduino IDE
  • Teensyduino

The default receiver and IMU choices are visible at the top of the Beta 1.3 sketch:

#define USE_PWM_RX
//#define USE_PPM_RX
//#define USE_SBUS_RX
//#define USE_DSM_RX

#define USE_MPU6050_I2C
//#define USE_MPU9250_SPI

That is the first design clue.

The project is meant to be edited.

Changing receiver type or IMU type is not hidden behind a GUI profile. You edit the sketch and build it for your hardware.

Receiver Support

The receiver options in Beta 1.3 are:

Receiver Mode Where It Fits
PWM Separate signal wire per radio channel
PPM Multiple channels on one timed signal
SBUS Digital serial receiver protocol common in RC
Spektrum DSM DSM satellite receiver support added in Beta 1.3

That also explains what is not there by default.

I did not see CRSF/ExpressLRS receiver support in the default sketch options.

That matters if you are coming from the ExpressLRS and Betaflight world.

An ExpressLRS receiver can be part of many aircraft, but dRehmFlight would need either a supported receiver output mode or additional CRSF parsing work in the code.

The Control Loop

The main loop is where dRehmFlight earns the post.

It reads like a small flight-control textbook translated into Arduino functions:

  1. Check arming state.
  2. Read IMU data.
  3. Estimate attitude with Madgwick.
  4. Convert radio input into desired roll, pitch, yaw, and throttle.
  5. Run one of the PID controllers.
  6. Mix the control outputs into motor and servo commands.
  7. Scale commands into pulse ranges.
  8. Apply throttle cut.
  9. Send motor and servo outputs.
  10. Read new radio commands and apply failsafe behavior.
  11. Hold the loop at 2 kHz.

The default loop rate call is explicit:

loopRate(2000);

That is useful for learning because timing is part of control.

PID gains, filters, sensor sampling, and ESC updates do not exist in isolation.

The Mixer Is the Best Part

The most important function for custom aircraft is controlMixer().

The default mixer is a normal quad-style example:

m1_command_scaled = thro_des - pitch_PID + roll_PID + yaw_PID;
m2_command_scaled = thro_des - pitch_PID - roll_PID - yaw_PID;
m3_command_scaled = thro_des + pitch_PID - roll_PID + yaw_PID;
m4_command_scaled = thro_des + pitch_PID + roll_PID - yaw_PID;

Then unused motor and servo outputs are set to zero.

For a normal FPV quad, that is not exciting.

For a custom VTOL, it is the exact point of the project.

This is where a tiltrotor, tailsitter, cyclocopter, tricopter, biplane VTOL, or odd servo-driven experiment becomes your aircraft instead of a preset.

That also means this is the dangerous part.

The mixer decides what physical actuator moves when the controller asks for roll, pitch, yaw, or throttle.

If that mapping is wrong, the aircraft can react in the opposite direction.

Outputs

The sketch has two output families:

  • up to six motor outputs using OneShot125-style ESC pulses
  • up to seven servo or conventional PWM-style outputs

The OneShot125 motor commands are scaled into 125 to 250 microsecond pulses:

m1_command_PWM = m1_command_scaled * 125 + 125;

The servo-style outputs are scaled into the familiar 0 to 180 range used by Arduino servo APIs.

That split is useful for VTOL work.

Not every aircraft is just four motors.

Some designs need motors plus tilt servos, aerodynamic control surfaces, vectoring surfaces, or other actuators.

Local Trial

I checked the local Arduino CLI state:

arduino-cli version
arduino-cli core list

The machine has Arduino CLI available, but only the ESP32 core was installed in the current CLI environment.

Then I tried the expected Teensy compile shape:

git clone https://github.com/nickrehm/dRehmFlight.git
cd dRehmFlight
arduino-cli compile --fqbn teensy:avr:teensy40 Versions/dRehmFlight_Teensy_BETA_1.3

That failed before compiling project code:

Platform 'teensy:avr' not found: platform not installed
Platform teensy:avr is not found in any known index
Maybe you need to add a 3rd party URL?

So the local result is:

Arduino CLI: present
ESP32 core: installed
Teensy core: not installed in Arduino CLI
dRehmFlight compile: blocked by missing Teensy board platform

That is not a dRehmFlight failure.

It means the local CLI environment was not prepared for Teensy builds.

The upstream path remains Arduino IDE plus Teensyduino.

How I Would Try It Safely

For a real experiment, I would separate the workflow into phases:

  1. Read the documentation before wiring anything.
  2. Build the default Teensy and MPU6050 setup first.
  3. Confirm receiver channel input over serial diagnostics.
  4. Confirm IMU orientation and calibration with props removed.
  5. Understand throttle cut and failsafe behavior.
  6. Test output direction with motors disabled or props removed.
  7. Modify controlMixer() only after the default loop is understood.
  8. Tether or restrain early tests according to the aircraft type.

This is not bureaucracy.

It is the cost of writing code that moves hardware.

Where It Fits Beside Betaflight

Betaflight and dRehmFlight are both open flight-controller firmware projects, but they are optimized for different users.

Project Best Fit
Betaflight FPV multirotors, common flight-controller boards, configurator workflows, blackbox analysis, presets, broad community support
dRehmFlight Arduino/Teensy learning, custom VTOL prototypes, readable control-loop experiments, unusual mixers

If you have a normal FPV quad, Betaflight is the practical default.

If you want to learn how a flight controller works from source, or build a strange aircraft that does not fit a normal mixer, dRehmFlight is more interesting.

That is why this project belongs after the Betaflight posts.

It is not the next layer of the same production stack.

It is the educational mirror.

FAQ

Is dRehmFlight a Betaflight replacement?

For most FPV pilots, no.

Betaflight has mature board target support, a configurator, presets, receiver integrations, OSD, blackbox logging, and a large FPV community.

dRehmFlight is better understood as readable Arduino/Teensy flight-controller source for learning and custom VTOL prototyping.

If you are building a standard freestyle quad, use Betaflight.

If you are trying to understand or modify the control loop for an unusual aircraft, dRehmFlight is the more approachable source study.

The practical difference is:

Question Betaflight dRehmFlight
Main audience FPV pilots and builders Learners, hackers, researchers, custom VTOL builders
Typical hardware Dedicated flight-controller boards Teensy 4.x plus external IMU wiring
Setup style Flash a target, configure in Betaflight App Edit Arduino sketch, upload through Arduino/Teensy workflow
Best workflow Tune and fly known aircraft layouts Understand and modify the control loop
Custom aircraft Possible, but inside a larger firmware ecosystem Central use case, especially through controlMixer()
Debug tooling OSD, configurator, blackbox ecosystem Serial prints, source inspection, Arduino-style iteration
What are the best dRehmFlight use cases?

dRehmFlight makes sense when the aircraft is unusual enough that the normal FPV firmware path is not the most useful starting point.

Good use cases include:

  • learning how flight-controller code works
  • teaching stabilization, PID, sensor fusion, and actuator mixing
  • prototyping custom VTOL aircraft
  • experimenting with tiltrotors, tailsitters, tricopters, bicopters, cyclocopters, or servo-vectoring designs
  • building a small test bench where every part of the control loop can be inspected
  • trying a new mixer before committing to a larger firmware architecture

Less ideal use cases:

  • a normal 5-inch freestyle quad
  • racing quads where Betaflight presets, targets, and Blackbox workflows are useful
  • aircraft where GPS navigation, missions, return-to-home, or mature failsafe stacks are required
  • users who want a GUI configurator instead of editing source

For normal FPV, Betaflight is more practical.

For understanding or inventing the flight-control behavior, dRehmFlight is more transparent.

Which tech stack does dRehmFlight use?

dRehmFlight is an embedded Arduino/Teensy firmware project.

The stack is roughly:

Layer Technology
Language Arduino-style C/C++
Build/upload workflow Arduino IDE plus Teensyduino
Microcontroller Teensy 4.0 by default, Teensy 4.1 compatible
Default IMU GY-521 MPU6050 over I2C
Optional IMU MPU9250 over SPI
Receiver inputs PWM, PPM, SBUS, Spektrum DSM
Attitude estimation Madgwick filter, with 6DOF and 9DOF paths
Control angle/rate PID controller functions
Actuator mixing custom controlMixer() function
Motor output OneShot125-style ESC pulses
Servo output Arduino Servo/PWM-style outputs
Debugging style Serial diagnostics and source-level inspection

So yes, this is embedded firmware.

It runs on a microcontroller connected to sensors, receiver inputs, ESCs, and servos.

It is not a server app, Docker service, browser app, desktop app, or PWA.

Does dRehmFlight support ExpressLRS or CRSF?

Not directly in the default Beta 1.3 receiver defines I inspected.

The included receiver options are PWM, PPM, SBUS, and Spektrum DSM.

That does not mean ExpressLRS is impossible in a broader hardware setup, but it does mean you should not assume the Betaflight-style CRSF workflow is already implemented.

For direct CRSF support, the code would need a CRSF receiver parser and integration into the radio command path, or the receiver would need to expose a mode that dRehmFlight already supports.

Could I use it on an iFlight Cidora SL5?

Not as a direct drop-in.

The iFlight Cidora SL5 is a 5-inch FPV quad platform normally built around a conventional FPV flight controller running firmware such as Betaflight.

dRehmFlight targets a Teensy plus IMU wiring model.

So the question is not “can I flash this to the Cidora board?”.

The realistic answer is: use Betaflight for the Cidora-style FPV hardware, and use dRehmFlight when you are building a custom Teensy-based controller or a separate experimental VTOL platform.

What makes the project good for learning?

The full control path is readable in a small number of files.

You can see receiver handling, IMU reads, Madgwick attitude estimation, PID controllers, output scaling, throttle cut, failsafe behavior, and the mixer without jumping across a large embedded firmware architecture.

That makes it easier to connect the math and code to the physical aircraft.

What should I modify first?

Do not start by changing gains and flying.

Start by confirming that the default receiver, IMU, arming, throttle cut, failsafe, and output directions all behave as expected with props removed.

After that, the most project-specific function is controlMixer().

That is where motor and servo outputs are mapped to throttle, roll, pitch, and yaw control demands.

Does it have a GUI configurator or Blackbox Explorer?

No, not like Betaflight.

dRehmFlight is Arduino-style source-first firmware.

Configuration happens by editing the sketch, selecting hardware options, calibrating, and uploading through the Arduino/Teensy workflow.

That is less convenient for normal pilots, but much better for learning what the controller is actually doing.

Is this safe for manned aircraft?

No.

Treat it as small model-aircraft experimentation code.

The upstream disclaimer is explicit that the software is not intended for manned vehicles, and any physical test should be done with props removed or the aircraft restrained until inputs, orientation, failsafe, and output direction are verified.

Final Thoughts

dRehmFlight is not impressive because it has the biggest feature list.

It is impressive because it keeps the flight-controller idea visible.

You can read the loop.

You can find the mixer.

You can see where receiver input becomes desired state, where IMU data becomes attitude, where PID output becomes actuator commands, and where safety gates are applied.

That is exactly the kind of project worth studying after Betaflight.

Betaflight shows how a mature FPV firmware ecosystem works.

dRehmFlight shows the control loop with fewer layers between you and the code.
